NSD15-12D12 — Isolated dual-output DC/DC converter

MEAN WELL NSD15-12D12 is a regulated dual-output DC/DC converter in the NSD15-D series, with a 9.4–36 V DC input range. It provides simultaneous +12 V and −12 V rails relative to COMMON, rated at 0.62 A per rail and 14.88 W total. This selection focuses on the positive +12 V rail; the module retains both outputs. Built-in remote ON/OFF control and free-air convection cooling support integration into equipment; observe the load, input and temperature limits below.

Download MEAN WELL NSD15-D Datasheet (PDF)
Download MEAN WELL EMI Testing Guidance (PDF)

Model section: datasheet PDF pages 9–10. Use the complete model specifications and connection drawing for this output selection.

Output selection

Selected output rail	Positive rail: +12 V
Output configuration	Simultaneous +12 V and −12 V outputs relative to COMMON; both rails belong to one physical converter.
Rated output current	0.62 A per rail (+12 V and −12 V).
Output current range	0.03–0.62 A on each rail. Maintain the stated minimum load on both outputs.
Rated output power	14.88 W total across both rails; this is not a separate 14.88 W allowance for each rail.
Series capability reference	The 15 W NSD15-D family is described as having a wide 4:1 DC input range. The exact input range and rated output power of this model are stated above; the series description does not enlarge those limits.

Electrical specifications

Rated DC input	12 V DC.
Input voltage range	9.4–36 V DC.
Input DC current	1.8 A at 12 V DC.
Shutdown idle current	20 mA; the general measurement conditions apply unless otherwise specified.
Efficiency	80% typical.
Capacitive load	1000 µF maximum per rail (catalog notation ±1000 µF).
Ripple and noise	100 mVp-p maximum at 25%–100% load.
Voltage tolerance	±2.5%. Includes setup tolerance, line regulation and load regulation.
Line regulation	±1.0% at 10%–100% load.
Load regulation	±1.0%.
Setup time	100 ms at rated DC input and full load.

Control, connections and protection

Pin assignment	Pin 1: +VIN; pin 2: −VIN; position 3: no pin; pin 4: CONTROL; pin 5: +VOUT; pin 6: COMMON; pin 7: −VOUT; pin 8: TRIM.
Remote ON/OFF control	CONTROL input is pin 4, referenced to pin 2 (−VIN). CMOS or open-collector TTL compatible. ON: +5.5 V DC minimum or open circuit. OFF: +2.5 V DC maximum or short CONTROL to pin 2.
Overload protection	Above 105% of rated output power; over-power limiting with automatic recovery after the fault is removed.
Overvoltage clamp	Positive rail: 13.8–18 V; negative rail: −13.8 to −18 V, as listed in the corresponding rail columns.
Short-circuit protection	Automatic recovery after the fault is removed. Short-circuit duration must not exceed 60 seconds.
Output trim range	±5.0% typical.
Output trim connection	Use the 0–100 kΩ trimpot arrangements shown in the datasheet: UP between TRIM (pin 8) and −VOUT (pin 7); DOWN between TRIM (pin 8) and +VOUT (pin 5). Observe this model’s typical adjustment range.

Operating conditions

Cooling and load derating	Free-air convection; horizontal installation. The curve shows 100% load from −25°C through +60°C, and 75% at +70°C. Follow the curve between marked points; the operating range ends at +70°C.
Environment	Working temperature: −25 to +70°C with derating. Working humidity: 0%–95% RH maximum. Storage: −40 to +85°C, 0%–95% RH.
Temperature coefficient	±0.03%/°C over 0 to +50°C.
High-altitude derating	Above 2000 m, reduce the applicable ambient-temperature limit by 3.5°C per 1000 m for this fanless converter.
General measurement conditions	Unless specifically stated otherwise, parameters are measured at 12 V DC input, rated load and +25°C ambient.
Ripple measurement	20 MHz bandwidth; a 12-inch twisted-pair wire terminated with 0.1 µF and 47 µF capacitors connected in parallel.

Safety and EMC integration

Safety standards	UL62368-1 and EAC TP TC 004 approved. BS EN/EN62368-1 is identified as a design reference.
Input/output isolation	1500 V DC.
Isolation resistance	100 MΩ between input and output, measured at 500 V DC, +25°C and 70% RH.
EMC emission	Compliance with BS EN/EN55032 (CISPR32) Class B and EAC TP TC 020, subject to the stated component test arrangement and final-equipment verification.
EMC immunity	Compliance with BS EN/EN61000-4-2, -3, -4, -6 and -8; BS EN/EN55035, light-industry level; EAC TP TC 020.
EMC test arrangement	The manufacturer tested the converter as a component mounted on a 230 × 230 × 1 mm metal plate. Reconfirm EMC compliance in the final equipment; the test plate is not stated to be a supplied accessory.
Suggested EMC input filter	The input filter drawing shows 80 µH inductive filtering and a polarized 680 µF capacitor across the converter input, on the converter side of the inductive elements. Select component ratings for the actual input range and verify the finished equipment.

Mechanical details and ordering

Dimensions	50.8 × 38.1 × 9.82 mm (L × W × H); catalog inch dimensions 2 × 1.5 × 0.387 inches.
Mechanical drawing coordinates	Pin-column spacing is 45.72 mm. On the input side, pin 1 to pin 2 is 5.08 mm and pin 2 to pin 4 is 10.16 mm; pin 4 is 6.35 mm from the bottom edge. On the output side, pins 5/6/7/8 have successive 10.16 mm spacings and pin 8 is 3.81 mm from the bottom edge.
Mechanical side-view details	The side view separately labels 9.82 mm, 10.8 mm and 13.33 mm vertical extents, a 5.84 mm board-level dimension, and pin/shoulder widths of 1 mm and 1.8 mm. Use the illustrated reference surfaces and allow clearance for the complete assembly and pins.
Drawing tolerance	±1 mm (±0.04 inch), as stated in the mechanical drawing.
Switching frequency	400 kHz, as labelled fosc in the PWM block diagram.
Built-in features	Built-in EMI filter; remote ON/OFF control; short-circuit, overload and overvoltage protection. Output-voltage trimming is included.
Reliability and production test	The series is presented as a low-cost, high-reliability design and receives a 100% full-load burn-in test.
MTBF	9469.6 K hours minimum by Telcordia SR-332 (Bellcore); 1673.2 K hours minimum by MIL-HDBK-217F at +25°C.
Weight and packing	30 g catalog packing reference per unit, not a measured net weight. Bulk packing: 180 pieces / 6.4 kg / 0.94 CUFT.
Manufacturer warranty	2 years.
Accessory scope	No dedicated accessory ordering code is specified in this series datasheet. External filter and trim components must be selected for the application.

Final-equipment EMC verification

Complete-system EMC verification	Verify EMC with the converter installed in the final equipment and connected to a representative load. Wiring, assembly and the application affect the result. Follow the model's specified EMC test conditions and any required external components; the linked EMI testing guidance does not certify the finished equipment.
