MEAN WELL NSD10-D series: Isolated dual-output DC/DC converter - NSD10-48D5

Description

NSD10-48D5 — Isolated dual-output DC/DC converter

MEAN WELL NSD10-48D5 is a regulated dual-output DC/DC converter in the NSD10-D series, with a 22–72 V DC input range. It provides simultaneous +5 V and −5 V rails relative to COMMON, rated at 1 A per rail and 10 W total. This selection focuses on the positive +5 V rail; the module retains both outputs. Built-in remote ON/OFF control and free-air convection cooling support integration into equipment; observe the load, input and temperature limits below.

Download MEAN WELL NSD10-D Datasheet (PDF)
Download MEAN WELL EMI Testing Guidance (PDF)

Model section: datasheet PDF pages 7–8. Use the complete model specifications and connection drawing for this output selection.

Output selection

Selected output rail Positive rail: +5 V
Output configuration Simultaneous +5 V and −5 V outputs relative to COMMON; both rails belong to one physical converter.
Rated output current 1 A per rail (+5 V and −5 V).
Output current range 0.05–1 A on each rail. Maintain the stated minimum load on both outputs.
Rated output power 10 W total across both rails; this is not a separate 10 W allowance for each rail.
Series capability reference The 10 W NSD10-D family is described as having a wide 4:1 DC input range. The exact input range and rated output power of this model are stated above; the series description does not enlarge those limits.

Electrical specifications

Rated DC input 48 V DC.
Input voltage range 22–72 V DC.
Input DC current 0.4 A at 48 V DC.
Shutdown idle current 20 mA. The shared catalog row specifies 12 V DC as the test input; it does not give a separate 48 V shutdown-current measurement.
Efficiency 78% typical.
Capacitive load 1000 µF maximum per rail (catalog notation ±1000 µF).
Ripple and noise 75 mVp-p maximum at 10%–100% load.
Voltage tolerance ±3.0%. Includes setup tolerance, line regulation and load regulation.
Line regulation ±1.0%.
Load regulation ±2.0%.
Setup time 100 ms at rated DC input and full load.

Control, connections and protection

Pin assignment Pin 1: +INPUT; pin 2: −INPUT (GND); pin 3: +OUT; pin 4: COMMON; pin 5: −OUT; pin 6: CONTROL.
Remote ON/OFF control CONTROL input is pin 6, referenced to pin 2 (−VIN). CMOS or open-collector TTL compatible. ON: +5.5 V DC minimum or open circuit. OFF: +2.5 V DC maximum or short CONTROL to pin 2.
Overload protection Above 105% of rated output power; over-power limiting with automatic recovery after the fault is removed.
Overvoltage clamp Positive rail: 5.75–7.5 V; negative rail: −5.75 to −7.5 V, as listed in the corresponding rail columns.
Short-circuit protection Automatic recovery after the fault is removed. Short-circuit duration must not exceed 60 seconds.

Operating conditions

Cooling and load derating Free-air convection; horizontal installation. The curve shows 80% load at −25°C, 100% from −10°C through +60°C, and 75% at +70°C. Follow the curve between marked points; the operating range ends at +70°C.
Environment Working temperature: −25 to +70°C with derating. Working humidity: 0%–95% RH maximum. Storage: −40 to +85°C, 0%–95% RH.
Temperature coefficient ±0.03%/°C over 0 to +60°C.
High-altitude derating Above 2000 m, reduce the applicable ambient-temperature limit by 3.5°C per 1000 m for this fanless converter.
General measurement conditions Unless specifically stated otherwise, parameters are measured at 48 V DC input, rated load and +25°C ambient.
Ripple measurement 20 MHz bandwidth; a 12-inch twisted-pair wire terminated with 0.1 µF and 47 µF capacitors connected in parallel.

Safety and EMC integration

Safety standards UL62368-1 and EAC TP TC 004 approved. BS EN/EN62368-1 is identified as a design reference.
Input/output isolation 1000 V DC.
Isolation resistance 100 MΩ between input and output, measured at 500 V DC, +25°C and 70% RH.
EMC emission Compliance with BS EN/EN55032 (CISPR32) Class B and EAC TP TC 020, subject to the stated component test arrangement and final-equipment verification.
EMC immunity Compliance with BS EN/EN61000-4-2, -3, -4, -6 and -8; BS EN/EN55035, light-industry level; EAC TP TC 020.
EMC test arrangement The manufacturer tested the converter as a component mounted on a 230 × 230 × 1 mm metal plate. Reconfirm EMC compliance in the final equipment; the test plate is not stated to be a supplied accessory.
Required input capacitor Add a 220 µF / 100 V electrolytic capacitor with ESR <1 Ω to the input line for proper operation.
Suggested EMC input filter The input filter drawing shows 80 µH inductive filtering and a polarized 680 µF capacitor across the converter input, on the converter side of the inductive elements. Select component ratings for the actual input range and verify the finished equipment.

Mechanical details and ordering

Dimensions 50.8 × 25.4 × 10 mm (L × W × H); catalog inch dimensions 2 × 1 × 0.394 inches.
Mechanical drawing coordinates From the drawing’s left edge, pins 1/2/6 lie at 15.24 mm and pins 3/4/5 at 35.56 mm. From the bottom edge: pins 6/5 at 2.54 mm, pin 2 at 10.16 mm, pin 1 at 15.24 mm, pin 4 at 12.7 mm and pin 3 at 22.86 mm.
Mechanical side-view details The side view separately labels 10 mm and 10.5 mm heights, a 3.81 mm lead extension, and pin/shoulder widths of 1.02 mm and 1.78 mm. Allow clearance using the complete mechanical drawing.
Drawing tolerance ±1 mm (±0.04 inch), as stated in the mechanical drawing.
Switching frequency 350 kHz, as labelled fosc in the PWM block diagram.
Built-in features Built-in EMI filter; remote ON/OFF control; short-circuit, overload and overvoltage protection.
Reliability and production test The series is presented as a low-cost, high-reliability design and receives a 100% full-load burn-in test.
MTBF 12288.5 K hours minimum by Telcordia SR-332 (Bellcore); 1878.5 K hours minimum by MIL-HDBK-217F at +25°C.
Weight and packing 20 g catalog packing reference per unit, not a measured net weight. Bulk packing: 300 pieces / 7 kg / 0.94 CUFT.
Manufacturer warranty 2 years.
Accessory scope No dedicated accessory ordering code is specified in this series datasheet. External filter components must be selected for the application.

Final-equipment EMC verification

Complete-system EMC verification Verify EMC with the converter installed in the final equipment and connected to a representative load. Wiring, assembly and the application affect the result. Follow the model's specified EMC test conditions and any required external components; the linked EMI testing guidance does not certify the finished equipment.
